Interacoustics
OtoRead Clinical OAE Screener
OtoRead is a handheld otoacoustic emissions device for DPOAE and TEOAE testing of newborns, children and adults. It is available in six licence versions covering screening and diagnostic protocols.
Need pricing or specifications?
Add this product to your request for quote list or contact our team. We'll respond with full details.
Key Features
- DPOAE and TEOAE testing in one handheld device
- Testing starts automatically when the probe is placed in the ear; results display as a green Pass or red Refer indication with frequency-specific result indication
- Four arrow keypad and colour display screens
- Pre-defined or user-defined test protocols
- Diagnostic version tests up to 12 kHz
- Optional small thermal printer; printing or data transfer to PC via Bluetooth
- Data transfer to the OtoRead PC Module; screening configurations can store data in OtoAccess Database via the HearSIM PC Module
- Software and database options compatible with Oz and HiTrack
- Replaceable probe tips, probe hook for hands-free stabilization and probe holder
Technical Specifications
Licence VersionsSix: Screener+, Screener DPOAE, Screener TEOAE, Standard DPOAE, Standard TEOAE, Clinical
DPOAE Screening Protocols2 fixed protocols (DP 2s and DP 4s), 2 to 5 kHz, 65/55 dB SPL, 6 dB SNR, 3 out of 4 frequencies for a pass, test time 2 or 4 sec per frequency
TEOAE Screening Protocols2 fixed protocols (TE 32s and TE 64s), 1.5 to 4 kHz, 83 dB pe SPL, 4 dB SNR, 3 out of 6 frequencies for a pass, maximum test time 32 or 64 sec
DPOAE Standard / Clinical1 screening plus 4 customizable protocols, 1.5 to 12 kHz, 12 frequency test protocols available
TEOAE Standard / Clinical1 screening plus 2 customizable protocols, user selectable frequencies between 0.7 and 4 kHz, 83 dB pe SPL
Internal StorageUp to 500 test results
Supplied Accessories20 exchangeable probe tips; eartips for newborn ears; probe hook; probe holder
