ENT Full HD Endoscopic System
Advanced Endoscopic Imaging for Every Procedure.
A comprehensive Full HD / 4K imaging solution for diagnostic and surgical ENT procedures — bringing together camera, monitor, LED light source, irrigation & suction unit, and mobile trolley in one ergonomic system.
Need pricing or specifications?
Add this product to your request for quote list or contact our team. We'll respond with full details.
Key Features
- Full HD / 4K Ultra-HD Endoscopic Visualization
- High-Resolution CMOS Camera Technology
- True-to-Life Color Reproduction and Image Clarity
- Medical-Grade 32" 4K Surgical Monitor
- Integrated Camera Control System
- Powerful LED Cold Light Source with Long Service Life
- Adjustable Brightness and Illumination Control
- Wide-Angle ENT Endoscope Compatibility
- Integrated Irrigation and Suction Pump System
- Real-Time Image Capture and Video Recording
- Multiple Video Outputs (HDMI, SDI, DVI, USB, LAN)
- Touchscreen User Interface for Easy Operation
- Compact Mobile Medical Trolley Design
- Smooth-Rolling Lockable Medical Casters
- Low-Noise Operation for Clinical Environments
- Autoclavable Endoscope Components
- Stable Performance for Continuous Procedures
- Ergonomic Workflow for Surgeons and Clinicians
- Reliable Image Processing and Enhancement
- Suitable for Diagnostic and Surgical ENT Procedures
Technical Specifications
ParameterENT Full HD Endoscopic System
Camera sensorHigh-performance CMOS
Image resolutionFull HD 1920 × 1080 / 4K Ultra-HD 3840 × 2160
Image qualityTrue-to-life colors with high clarity
Viewing angle178° (H / V)
Video outputsHDMI · SDI · DVI · BNC · USB · LAN
RecordingReal-time image & video capture
CompatibilityWide-angle ENT endoscopes
Image processingAdvanced digital processing and enhancement
Light sourceLED cold-light source
Output power100 W
Color temperature3000 – 7000 K
Minimum illumination0.3 Lux
Brightness controlAdjustable (PWM dimming)
Light cableØ2.4 mm × 2 m
Service life> 50,000 hours
CoolingInternal, low-heat, long-life LED illumination
Power supplyAC 85 – 264 V, 50/60 Hz
Input power150 VA
Irrigation systemIntegrated irrigation pump
Suction systemIntegrated suction pump
Pump flow range0 – 350 mL/min
Suction range100 – 30,000 mL/min
Noise level< 45 dB(A)
Operating environment5 °C – 40 °C · Humidity < 80%
Monitor size32" Medical Monitor
Panel resolution3840 × 2160 (4K UHD)
TrolleyWheels, drawer & lockable casters
MaterialAluminum alloy · medical-grade components
System weightApprox. 33 kg
ComplianceDiagnostic & surgical ENT procedures
