Orion Auto-Traverse Rotary Chair
The Orion Auto-Traverse is an enclosed rotary chair for vestibular assessment. It delivers computer-controlled rotational stimuli and off-axis centripetal acceleration for dynamic subjective visual vertical testing.
Need pricing or specifications?
Add this product to your request for quote list or contact our team. We'll respond with full details.
Key Features
- Enclosed rotary chair with off-axis centripetal acceleration
- Test battery includes Sinusoidal Harmonic Acceleration (SHA), step velocity testing, VOR suppression testing with a built-in laser fixation target, visual VOR using the built-in optokinetic drum, and static and dynamic subjective visual vertical (SVV) tests
- Dynamic SVV uses an XY-axis laser-projected line in a fully darkened environment, with a handheld remote allowing the patient to adjust the line
- Customizable SVV protocol for desired line offset and number of trials
- When combined with VE525 VNG: full-field optokinetics, optokinetic after nystagmus (OKAN), horizontal and vertical saccades, smooth pursuit and gaze testing
- Optional pediatric add-on package with car seat adapter, in-booth observation camera and a small-face goggle
- Optional EOG add-on for recording without infrared camera goggles
Technical Specifications
SHA Frequency Range0.01 to 1.28 Hz
Step Velocity TestingUp to 350 deg/sec
VOR Suppression Test Range0.01 to 1.28 Hz
Maximum AccelerationUp to 200 deg/sec2
Dynamic SVV Velocity300 deg/sec, on or off-axis
Lateral MovementComputer-controlled step motor provides up to plus or minus 7 cm lateral movement from centre axis
SVV Laser Adjustment Increment0.1 degrees
Maximum Patient Weight400 lbs
SoftwareVisualEyes 525
