Lifecare® USA
T-Piece Resuscitator
The Lifecare® USA T-Piece Resuscitator is a neonatal respiratory support system designed to deliver controlled, consistent positive pressure ventilation for newborns and infants. It allows clinicians to accurately regulate PIP and PEEP while maintaining stable oxygen delivery, supporting safe and confident resuscitation. Suitable for delivery rooms, NICUs, operating rooms, and emergency neonatal care, it operates without electrical power, ensuring dependable performance in critical moments. 91
Need pricing or specifications?
Add this product to your request for quote list or contact our team. We'll respond with full details.
Key Features
- Designed for infants weighing under 10 kg
- Suitable for delivery rooms, maternity wards, NICUs, and neonatal transport
- Air-driven system requiring no electrical power
- Intuitive operation that reduces caregiver fatigue
- Integrated PEEP, suction, and oxygen supply functions
- Independent control of oxygen concentration and flow rate
- Oxygen concentration adjustable from 21% to 100% with high accuracy
- Compliant with NRP and ILCOR neonatal resuscitation guidelines
Technical Specifications
ParameterT-Piece Resuscitator
Patient RangeDesigned for infants weighing up to 10 kg
Oxygen Accuracy±3% V/V
Ventilation TypeT-piece resuscitation with controlled PIP
Output Flow Range0 — 15 L/min
PIP Range1 — 60 cmH‡O (factory preset at 20
Gas Supply TypeMedical oxygen and medical air
Supply Pressure300 — 500 kPa (45 — 75 psi)
PEEP RangeUp to 28 cmH‡O depending on flow rate
Dead Space Volumed 6 mL (including airway accessories)
Maximum Pressure (Pmax)Adjustable up to 60 cmH‡O
Vacuum Suction Range0 — 140 mmHg (0 — 18.67 kPa)
Manometer Range— 10 to 80 cmH‡O
Ingress ProtectionIPX4
Oxygen Concentration Range21% — 100%
Operating Temperature18°C — 40°C
