Lifecare® USA
Urine Analyzer
The Lifecare® USA Urine Analyzer is a high-throughput urinalysis system designed for rapid screening and monitoring of urinary parameters.
Need pricing or specifications?
Add this product to your request for quote list or contact our team. We'll respond with full details.
Key Features
- High-throughput analysis supporting up to 600 test strips per hour
- Broad test menu covering biochemical, physical, and ratio-based parameters
- Advanced photoelectric colorimetry for accurate optical detection
- Automatic ACR and PCR ratio calculation for clearer clinical interpretation
- Large 10-inch LCD touchscreen for intuitive operation
- Built-in thermal printer for immediate result output
- High-capacity internal storage for up to 100,000 test records
- Multi-language interface supporting international clinical use
- Integrated barcode scanner for efficient sample identification
- Seamless connectivity with HIS/LIS and external laboratory systems
Technical Specifications
ParameterUrine Analyzer
Test PrincipleSemi-automatic photoelectric colorimetry
Barcode ScannerBuilt-in (EAN-13, EAN-8, Code-39, Code-128)
Wavelength Range300 — 850 nm (typical: 450,
ConnectivityRS-232, USB, Bluetooth, WiFi, LAN, HIS/LIS, HL7
PrinterIntegrated thermal printer
Test SpeedUp to 600 strips per hour
Transmission Rate115200 bps
Test ParametersURO, BIL, KET, BLD, PRO, NIT, LEU, GLU,
Power SupplyAC 220V, 50Hz; Built-in DC 14.8 — 16.8V
Display10-inch LCD touchscreen
Power Consumption80 VA
Data Storage CapacityUp to 100,000 patient records
Standby TimeUp to 12 hours (laboratory conditions)
Ratio AnalysisAutomatic ACR and PCR
Dimensions342 × 300 × 248 mm (L × W × H)
