United Imaging uCT 780
CT Scanner
An advanced 160-slice CT with fine detail at low dose.
The uCT 780 is an advanced 160-slice CT scanner offering superb precision, speed and image quality. Its fully integrated Z-Detector enables low-dose data acquisition with fine detail, while a fast 0.3-second rotation produces exquisite images of the heart and other organs. Born with AI, the DELTA deep-learning reconstruction bridges dose reduction and patient-centric care.
Need pricing or specifications?
Add this product to your request for quote list or contact our team. We'll respond with full details.
Key Features
- Advanced 160-slice CT scanner for whole-body imaging: head, neck, chest, abdomen, cardiac and vascular
- Fast 0.3-second rotation with 150 ms temporal resolution, producing sharp, motion-free images of the heart and other moving organs
- Fine 0.5 mm minimum collimation for high-detail cross-sectional images
- Powerful 100 kW generator with five scan modes (70 to 140 kV) to tailor each exam to the patient and clinical question
- Fully integrated Z-Detector that lowers electronic noise to almost single-photon level, giving higher signal quality and more efficient use of the X-ray dose
- High-detail 1024 × 1024 reconstruction handling 360 million voxels, with fast reconstruction up to 60 images per second
- DELTA deep-learning (AI) reconstruction that dramatically improves the dose vs. quality balance: up to 80% less dose at the same image detail, or up to 98% less noise at the same dose
- Works across both projection and image space for cleaner, clearer results
- AI-assisted automation that sets up scans and selects cardiac phases for you, reducing operator workload
- Cardiac-ready with coronary CTA and adaptive phase selection, plus one-stop cardiac + aortic CTA from a single contrast injection
- Low-contrast vascular imaging (CTA & CTV) using a 70 kV high-SNR mode
- Dedicated low-dose 70 kV protocols for pediatric patients
- Single-click, standardized post-processing workflow for fast, consistent results
Technical Specifications
ParameterSpecification
Slices per rotation160
Rotation speedUp to 0.3 s / 360°
Temporal resolution150 ms native
Min. collimation0.5 mm
Generator power100 kW
Scan modes70 · 80 · 100 · 120 · 140 kV
DetectorFully integrated Z-Detector
Electronic noiseReduced to single-photon level
Reconstruction matrix1024 × 1024
Voxel throughput360 million voxels; up to 60 IPS
AI reconstructionDELTA 3D neural network
Dose reductionUp to 80% at same LCD
Noise reductionUp to 98% at same dose
LCD improvementUp to 155% at same dose
Reconstruction domainProjection & image space
AI automationScan setup & cardiac phase selection
CardiacCoronary CTA; adaptive phase selection
One-stop CTACardiac + aortic, single contrast injection
VascularCTA & CTV (70 kV high-SNR mode)
Whole bodyHead, neck, chest, abdomen
PediatricLow-dose 70 kV protocols
Post-processingSingle-click, standardized workflow
